In designing and manufacturing 230DE T10 Edilgrappa has developed a Hydraulic Shear Cutter with professional application as crushing brick and concrete walls.
A right solution for controlled demolition and renovation sectors, is the Edilgrappa Hydraulic Shear Cutter 230DE T10.
Ideal equipment for crushing reinforced concrete walls, the 230DE T10 is especially used for rescue operations after natural disasters such as earthquakes.
Functioning with a separate hydraulic control unit.
| Jaws opening | 230 mm |
| Crushing capacity | 200 mm |
| Crushing force | 104 Kn (10.6 t) |
| Working pressure | 70 Mpa (700 bar) |
| Cylinder | Double acting |
| Weight | 23.4 kg |
| Dimensions (closed) LxWxH | 874 x 426 x 212 mm |
| Dimensions (open) LxWxH | 801 x 510 x 212 mm |
