MU26DE

MU26DE

Operations with the Flat Bar Cutting Head (TP120x12DE – 150.00056).
Double acting
Available Version 120V (US plug) – 150.00103

Edilgrappa has developed electro-hydraulic tool MU26DE capable of performing operations with the Flat Bar Cutting Head (TP120x12DE – 150.00056).
Its small size makes the MU26DE a very useful Portable Rebar Bender and Cutter when working in small and complicated spaces, where portable tools are needed.
The MU26DE can be easily transported wherever it is needed thanks to its integrated electric motor. Different versions are available depending on the electrical network of the country of application.



Technical specifications
Technical Specifications
Force 40 t
Working pressure 64 MPa (640 bar)
Power supply Main
Motor 230V: 1400 W – 50Hz – 6.8 A

120V: 1100 W – 60Hz – 11 A
Cyinder Double acting
Weigth 15.7 kg
Dimensions LxWxH 440 x 181 x 247 mm
