Steel, copper and aluminium
Ideal for building and industrial works
Double acting
Available Versione 120V (US plug) – 150.03044
Edilgrappa PZN28DE Protruding Die, is a electro-hydraulic tool produced in Italy to punch steel, copper and aluminium.
PZN28DE Protruding Die: made by Edilgrappa in Italy for building and industrial works.
The PZN28DE is a that can be easily transported wherever it is needed thanks to its integrated electric motor. Different versions are available depending on the electrical network of the country of application.
| Punching capacity | see charts below |
| Max punch | ø 30 mm |
| Punching force | 275 kN (28 t) |
| Working pressure | 55 Mpa (550 bar) |
| Power supply | Main |
| Motor |
230V: 1400 W – 50Hz – 6.8 A 120V: 1300 W – 60Hz – 11 A |
| Cylinder | Double acting |
| Weight |
28.6 kg (150.01972 – 150.03044) 25.4 kg (150.01963 – 150.02384) |
| Dimensions LxWxH | 645 x 229 x 348 mm |
