DFE080

DFE100

DFE140

N. of available ways

6-8-10

6-8-10

6-8-10

Nominal flow rating

In steady conditions

25 l/min

50 l/min

80 l/min

Operating pressure (max)

Withous drain

200 bar

200 bar

200 bar

With drain

315 bar

315 bar

315 bar

Available nominal voltage

VDC

12-24

12-24

12-24

VAC 50 Hz (with C04 connector)

24-110-220

24-110-220

24-110-220

Nominal power

W

38

60

60

Internal leakage A(B)→T

∆p=100 bar with fluid and valve at 40°C

7 cm3/min

10 cm3/min

10 cm3/min

Tie rods tightening torque

9,8 Nm

18 Nm

25 Nm

Fluid

Mineral base oil

Fluid temperature

with NBR seals

from -20° to 80°C

with FPM seals

from -20° to 100°C

Viscosity

Operating range

from 15 to 75 mm2/s

Min

12 mm2/s

Max

400 mm2/s

Max level of contamination

-/19/16 - ISO 4406

Ambient temperature for working conditions

from -20°C to 50°C
