Nominal flow rating (open center circuit)

On inlet port with compensator @ stand-by (margin pressure)

150 l/min @ 9 bar

On working ports with compensator @ stand-by (margin pressure)

100 l/min @ 7 bar

On working ports without compensator @ stand-by (margin pressure)

130 l/min @ 9 bar

Max pressure

Inlet port P

315 bar (4500 psi)

Working ports A and B

315 bar (4500 psi)

Back pressure max

On outlet port T

25 bar (363 psi)

On drain port L

2,5 bar (3,63 psi)

Standard internal leakage A(B)→T

∆p=100 bar

16 cm3/min

With port valves, ∆p=100 bar

21 cm3/min

Fluid

Mineral oil

Fluid temperature range

With seals NBR

from -20° to 80°C

With seasl FPM

from -20° to 100°C

Viscosity

Operating range

from 15 to 75 mm2/s

Min

12 mm2/s

Max

400 mm2/s

Contamination level

-/18/15 - ISO 4406

Enviromental temperature for working conditions

With mechanical devices

from -40° to 60°C

With hydraulic, pneumatic devices

from -30° to 60°C

With electric, electrohydraulic devices

from -20° to 50°C
